DISTRIBUTION PANEL STV 711

Watertight Distribution Panels Series 700 makes direct protection of switches mounted externally possible. Circuit breakers are available in 6 A, 10 A, 16 A, 20 A or as button in 10A. Combine user comfort through a simple design and technical dependability. Each circuit is switched and protected by a watertight thermic circuit breaker with its own rocker switch (ETA). It contains an integrated light diode that shows circuit status. In case of short circuit, the breaker switches automatically off and the light is off. Once the problem is corrected, the breaker can be manually pushed to ON position. The circuit breaker has an intern mechanism that will not react (turn on) during a problem in circuitry, there by protecting circuits. Self adhesive labels are included.

Features:

• Order no.: STV 711
• Voltage: 12V/24V
• Panel color: dark gray
• Color switches: black
• Color LEDs on the switch: white
• Switch: 1x ETA with thermic contact breakers 10A
• Actuator has to be ordered separately
• Weight: 0.2 kg
• Overall dimensions (WxHxD) mm: 43 x 69 x 65
• Warranty: 2 years
