PROSPLIT D - 130A/3 OUTPUTS
New product
Sterling Power split charge diode 130A for 3 battery banks. Battery Isolators use diodes that have been designed for the battery isolator to have a lower voltage drop, thus less heat loss, than the common off the shelf battery isolator.
More info
Sterling Marine has developed a range of low cost split charge diodes. These diodes have enhanced performance over conventional diodes and at a lower cost. The difference is in the devices. All other split charge diode manufacturers use conventional alternator diodes, which at low current flow have about a 0.93 voltage drop. When the full rated current of these diodes is approached, the voltage drop increases to about 0.95 volts. This results in excessive heat and power loss across the diode. Most off the shelf isolators use diodes designed to be used in the alternator itself where air movement is used to keep them cool. Unfortunately battery isolators don’t have forced air cooling.
-
Model: ProSplit D130A3
-
Max. current: 130A
-
Input (alternator): 1
-
Outputs: 3
- Low voltage drop diodes
- Gold plated terminals
- Protection contacts
- Size (LxWxD): 190 x 120 x 90
-
- Weight: 1,9 kg
- Warranty: 2 years
