RA3072HD 4KW 72" HD COLOR OPEN ARRAY
New product
The Raymarine RA3072HD Open Array Radar Scanner brings the power of Raymarine’s HD Color technology to radar delivering unmatched performance and ease-of-use.
More info
Raymarine’s HD Color technology brings radar users the power of digital signal processing with a truly adaptive transmitter and receiver that automatically adjusts to changing environmental and sea conditions. HD Color radar delivers a dramatically clearer radar picture with crisp, well-defined contact echoes and life-like target presentation. HD Color radar’s wide receiver bandwidth and high-speed digital processing detect weak and distant contacts that are invisible to traditional analog radar systems, while virtually eliminating clutter, noise and false echoes.
The RA3072HD Open Array Radar Scanner combines Raymarine’s 72” open array antenna with a powerful 12kW HD Color antenna pedestal with a 72 mile maximum range. The system also includes the VCM100 voltage converter, 15-meter digital pedestal cable, mounting hardware, mounting template and instructions. SeaTalkhs network compatible for Raymarine navigation systems including:
- G-Series (GPM400)
- E-Series Widescreen (E90W, E120W, E140W)
- C-Series Widescreen (C90W, C120W, C1440W)
- E-Series Classic (E80, E120).
Not compatible with C-Series Classic (C70, C80, C120.)
Features include:
- Order no.: T92169
- Exclusive Raymarine HD Digital radar technology
- Adaptive digital receiver automatically adjusts to changing environmental and sea conditions for a dramatically clearer picture
- Fast digital receiver processor
- Delivers 256 color target levels
- Dual range capable
- Thin interconnect cable
- Supplied with remotely mounted VCM100 voltage converter module
- 12 or 24 volt operation
- Warranty: 3 years (registration on the website)
Specifications:
- Voltage: 10.7-32 volts for 12v, 24v systems
- Power consumption (typical) watts: 46W, Standby: 30W
- Operating temperature range: -10°C to +55°C D6
- Non-operating temperature range: -20°C to +70°C C6
- Waterproofing standard: IPX6
- Scanner power and type: 4kW HD Color
- Antenna Size: 6' (72")
- Scanner cable length: 15m standard (5m, 10m & 25m option)
- Pedestal Weight: 29,0 kg
- Dimensions: (WxHxD) mm: 1918 x 402 x 324
